| Place of Origin: | China |
| Hàng hiệu: | TONGDA |
| Chứng nhận: | CE& ISO9001& Bundersrepublik deutschland patents |
| Model Number: | HTSII-3L |
| Minimum Order Quantity: | 1set |
|---|---|
| Giá bán: | Negotiable |
| Packaging Details: | 20GP |
| Delivery Time: | 60 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 50SETS/MONTH |
| Screw: | 70mm | Output of HDPE: | 70kg/hr |
|---|---|---|---|
| Suitable material: | PE/PP/LDPE/HDPE | Max. volumen: | 1000 ml |
| Station: | Double stations | View strip: | Optional |
| Color: | White/Blue/Yellow/Orange | ||
| Điểm nổi bật: | bottle blow moulding machine,plastic bottle manufacturing machine |
||
50ml 100ml 200ml 350ml small plastic pesticides bottles Blow Moulding Machines HTSII-3L
double station automatic bottle molding machine SRB60-1C is widely used in PVC plastic bottle and container making field, sport joyshaker water bottle making field, detergent liquid soap bottle making field, small toy parts field, also used for other small round or square pvc containers.
Extrusion blow molding machine technical specification:
| Model | HTSII-3L | |
| Max. Product Volume | (L) | 0.35L |
| Dry cycle | (pc/h) | 800*2 |
| Screw Diameter | (mm) | 70/80 |
| Screw L/D ratio | (L/D) | 25 |
| Screw drive power | (KW) | 22/30 |
| Screw heating capacity | (KW) | 4.2/8 |
| No. of heating zone | (ZONE) | 3/4 |
| Max. Output of HDPE | (Kg/hr) | 70/110 |
| Oil pump drive power | (KW) | 11 |
| Clamping force | (KN) | 80 |
| Platen distance | (mm) | 160~320 |
| Mold moving stroke | (mm) | 500 |
| Max. Size of Mold(W*H) | (mm) | 450*250 |
| Max. Die diameter | (mm) | 30/45 |
| Die heat capacity | (KW) | 4.3 |
| No. of heating zone | (ZONE) | 13 |
| Central distance of Quad head | (mm) | 70/100 |
| Blowing pressure | (Mpa) | 0.6 |
| Air volume | (M3/MIN) | 0.4 |
| Cooling water pressure | (Mpa) | 0.2~0.3 |
| Water consumption | (L/MIN) | 80 |
| Size of machine ( L*W*H) | (m) | 3.2*2.7*2.5 |
| Weight of machine | (TON) | 8 |
Extruson blow molding machine suppliers of main parts:
a) Hydraulic Parts
| Name | Supplier |
| Oil Pump | PARKER or SUNNY, America |
| Valve | YUKEN or SUNNY |
| Hose, Joint | PARKER SIR |
| Sealer | Top DZ Europe |
b) Electrical Parts
| Name | Supplier |
| Microcomputer Control System | MITSUBISHI PLC, Japan |
| Touch Screen | HITECH color screen, Taiwan |
| Temperature Controller | MITSUBISHI, Japan |
| Conductor | SCHNEIDER |
| Air Switch | SCHNEIDER |
| Motor | SIMENS BEIDE Asynchronous Motor |
| Power Resource | MEAN WELL, Taiwan |
| Inverter | MITSUBISHI |
c) Pneumatic Parts
| Name | Supplier |
| Solenoid Valve | FESTO, Germany |
| Cylinder | FESTO, Germany |
Extrusion blow molding machine installation, commissioning and training:
If the buyer needs seller to send technicians to workshop for supervising the erection and start-up, seller must support and send sufficient number of technicians and keep duration of stay in workshop. Usually it’s about 3~5 days in this duration. The first day is that when our technician is at the airport to factory of buyer. And from the first day, the buyer has to pay US$80 per day. And all accommodation, visa application & air ticket will be born by the buyer.
Người liên hệ: Mr. Figo Hussian
Tel: +8613773258862
